Installing an air conditioner

When the air conditioner is in operation, condensation is usually generated, which is normal. This is not a leak, it indicates that the device is working properly. A condensate collection tray is also provided to collect this waste. The water is then pumped away through drains that connect to the exterior of the property. This natural evaporation of condensation must be continuous.

When the evacuation of condensate is not possible naturally, SFA offers you solutions to collect the condensate from your air conditioner and pump them quietly and discreetly to teh nearest drain point of your building.

Installing an air conditioner

SFA Sanicondens Clim Mini S is a miniature pump for discharging the condensate waste discharged by air conditioners with a power of up to 8 kW. Ease of installation, both aesthetic and acoustic discretion, this new SFA product is also available in Sanicondens Clim Pack S, a complete solution for the installation including a Sanicondens Clim Mini S pump, a white trunking with reversible 90 degree cover (left / right ).

Compatible with air conditioners up to 8 kW power, Sanicondens Clim Mini S is particularly quiet with a sound level of only 21 dB (A), which is the quietest on the market. It should also be noted that this acoustic performance, synonymous with comfort, is combined with a flow rate of 9 l / h (+/- 15%) with maximum suction, between the detection unit and the pump, up to 2 meters and a discharge condensates up to a height of 6 meters.

Allowing a maximum incoming water temperature of 35 ° C, Sanicondens Clim Mini S has a 16 mm diameter inlet and a 6 mm outlet. Made in France and having an IP 20 electrical protection rating, Sanicondens Clim Mini S is also equipped with a safety feature, namely thermal protection (130 ° C), as well as an anti-overflow alarm connection.

For maintenance and safety it is designed with a transparent base and with an anti-siphon system with vacuum breaker as standard. This prevents any pressure overload to protect your installation and extend the life of the air conditioner.

Very compact, (detection unit: 74 x 37 x 37.5 mm - pump unit: 57 x 32 x 105 mm), the assembly of the Sanicondens Clim Mini S is simple and easy and it is supplied with fixing accessories and connections (1.2 m flexible hose, detector support, vent tube, power cable and vacuum breaker).
